25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer

25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer
25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer

Large Image :  25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer

Product Details:
Place of Origin: CHINA
Brand Name: ALSTON
Certification: CCC, ISO, CE
Model Number: ATM3316DT
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $16000-$22000
Packaging Details: Nude, Waxing before delivery
Delivery Time: 15-30 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 30 units per month

25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer

Description
Product Name: Rear Dump Trailers Type: Truck Trailer
Suspension: Mechanical Suspension Brake System: WABCO Valve
Dimension: 9600x2550x3860mm Loading Capacity: 25cbm
Highlight:

25cbm Rear Dump Trailers

,

Hydraulic Rear Dump Trailers

,

U Shape 3 Axle End Dump Trailer

25cbm Hydraulic U-Shape 3 Axle Rear End Tipper Truck Dumper Semi Trailer

Rear Dump Trailers Advantages:

1. We are one of the largest semi-trailer factories in China. Our factory adopt high tensile steel materials,
together with advanced production equipment, superb welding technology and strict quality control procedures.
2. We have exported a lot of this type rear dump trailers to your country, and we are familiar with the transportation

configuration requirements of your country. Our customers are so satisfied with our truck trailers.
3. Our team is consisted of a group of diligent and enterprising people, working to respond client inquiries and

questions all the time. Most problems can be solved within 12 hours.
Our 3 axle tipper trailer is outstanding due to the excellent driving and tipping characteristics. The dumper trailer
drives safely on the road thanks to a low overall centre of gravity and torsion-resistant rigid frame structure.

                            REAR DUMP TRAILERS SPECIFICATIONS

 Model3 axle 25cbm Rear Dump Trailer
 FunctionTransport sand, stone, gravel
Dimension
 Overall Size (L×W×H)mm9600×2550×3860mm
 Inner Size (L×W×H)mm8300×2330×2000mm
 Wheel base6870+1310+1310mm
Weight
 Payload68,000kg
 Tare weightApprox12,000kg
 G.V.W.R.Approx 80,000kg
Body details
 Main beamMaterial Q345 carbon steel, upper plate 18mm, down plate 18mm, middle plate 8+8mm.
 Body thickness6mm
 Bottom thickness8mm
 Hydraulic SystemFull set of HYVA Hydraulic System 202
Frame
 Axleheavy duty, 3×13Ton capacity, FUWA brand
 SuspensionLeaf spring suspension, 90mm×16mm×10pcs
 Tire12R22.5 12units Taitong Brand
 Kingpin50mm/90mm removable
 Landing gearYahua brand, 28ton, double speed, heavy duty
 Tool box1pcs
 Spare wheel carrier2pcs


25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 0

Flat Rack Container                                        Bulk Ship

25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 1
25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 2
25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 3
25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 4
25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 5
25cbm Hydraulic Rear Dump Trailers , U Shape 3 Axle End Dump Trailer 6
